Tenis Play Ground Chain Wire Fence 50mm x 50mm ,chain wire park chain wire fencing for sale

Brand Name : LNF-Chain link Fence fabric

Model Number : 2.5" etc

Certification : ASTM392 ASTM396

Place of Origin : American Design China Made

MOQ : 500 liner meter

Price : 3.88$ per liner meter

Payment Terms : TT30% deposit balance 70% at sight of finished products

Supply Ability : 10000 liner meters

Delivery Time : 7 work days

Packaging Details : All metal Pallets

Materials : Q235 steel

Color : Any Ral Color

Treatment : Hot Dipped Glavanized,Powder Coated

Mesh Opening : 65mm x 65mm 50mm x 50mm ,55mm x 55mm ,75mm x 75mm ,60mm x 60mm ,80mm x 80mm

Diameter : 1.5mm to 5.00mm

Type : Woven Mesh

Warranty : 5 -25 years depand on the treatment

Main Market : Europea ,Middle East ,USA ,AU etc

Accessoires : Tension Band ,Bar ,Steel Plate and Post Caps etc

Customized : Available

Feature : Diamond Mesh

Application : Garden Fence, Farm Fence, Residential Fence, Highway Fence, Railway Fence, Balcony Fence, Airport Fence, Stadium Fence, Municipal Fence, Bridge Fence, Stair Fence, Air-Condition Fence,and Son

Trade Mark : N/M

Sample : Free but pay freight cost

Nickname : CYCLONE FENCE,wire netting, wire-mesh fence, chain-wire fence, cyclone fence, hurricane fence, or diamond-mesh fence

Contact Now

Tennis Play Ground Chain Wire Fence 50mm x 50mm, chain wire park chain wire fencing for sale

Chain link fence is made from galvanized or PVC coated iron wire, to fix with posts, brace, and fittings to build a chain-link fence system in the park, tennis court, airport, and other places. Also can be used for animal breeding. Chain link is mainly divided into galvanized, PVC, PE-coated three finishing chain link fence with easy construction and maintenance, bright colors, which are the preferred products to beautify the urban environment.

2.chain link fence common specification:

Tenis Play Ground Chain Wire Fence 50mm x 50mm ,chain wire park chain wire fencing for sale

The dimension of Galvanized Chian Link Fence
Mesh Wire Diameter Width Length
40mmx40mm 1.8mm--3.0mm 0.5m--4.0m 5m-25m
50mmx50mm 1.8mm--3.5mm 0.5m--4.0m 5m-25m
60mmx60mm 1.8mm--4.0mm 0.5m--4.0m 5m-25m
80mmx80mm 2.5mm--4.0mm 0.5m--4.0m 5m-25m
100mmx100mm 2.5mm--4.0mm 0.5m--4.0m 5m-25m

Tenis Play Ground Chain Wire Fence 50mm x 50mm ,chain wire park chain wire fencing for sale

Dimension of PVC Coated Chian Link Fence
Mesh Wire Diameter Width Length
40mmx40mm 2.8mm--3.8mm 0.5m--4.0m 5m-25m
50mmx50mm 3.0mm--5.0mm 0.5m--4.0m 5m-25m
60mmx60mm 3.0mm--5.0mm 0.5m--4.0m 5m-25m
80mmx80mm 3.0mm--5.0mm 0.5m--4.0m 5m-25m
100mmx100mm 3.0mm--5.0mm 0.5m--4.0m 5m-25m

Tenis Play Ground Chain Wire Fence 50mm x 50mm ,chain wire park chain wire fencing for sale

galvanized chain link fence weight :

Mesh Gauge(BWG) Weight(kg/m2) Width(m) Length(m)
1/2" 14 4.4 0.5m-5.0m 1.0m-50m
3/4" 12 6.0 0.5m-5.0m 1.0m-50m
3/4" 14 3.3 0.5m-5.0m 1.0m-50m
3/4" 16 1.9 0.5m-5.0m 1.0m-50m
1" 12 4.0 0.5m-5.0m 1.0m-50m
1" 14 2.4 0.5m-5.0m 1.0m-50m
1" 16 1.4 0.5m-5.0m 1.0m-50m
5/4" 12 3.2 0.5m-5.0m 1.0m-50m
5/4" 14 1.92 0.5m-5.0m 1.0m-50m
3/2" 10 4.0 0.5m-5.0m 1.0m-50m
3/2" 12 2.7 0.5m-5.0m 1.0m-50m
3/2" 14 1.6 0.5m-5.0m 1.0m-50m
2" 8 4.16 0.5m-5.0m 1.0m-50m
2" 10 3.0 0.5m-5.0m 1.0m-50m
2" 11 2.5 0.5m-5.0m 1.0m-50m
2" 12 2.0 0.5m-5.0m 1.0m-50m
2" 9 3.2 0.5m-5.0m 1.0m-50m

Chain link fence surface treatment :

Surface treatment Min Max
Electro-Galvanized 15g/m2 25g/ m2
Hot dip galvanized 30/ m2 366g/m2
PVC/PE Coated 400microns 1000microns

3.Galvanized chain link fence :

Tenis Play Ground Chain Wire Fence 50mm x 50mm ,chain wire park chain wire fencing for sale

4.PVC coated chain link fence :

Tenis Play Ground Chain Wire Fence 50mm x 50mm ,chain wire park chain wire fencing for sale

CHOOSING THE BEST TYPE :

The main considerations are the height of the fence, the thickness of the wire, and the finish of the wire.

Height

Chain link fences may be anything from 3 feet the 12 feet high, the highest being generally used for surround sports areas where it is important to prevent balls escaping. Lower chain link fences for use around homes can be fitted with privacy slats.

Thickness of wire

The thickness of the wire for chain link fences can be quite confusing. Manufacturers will usually refer to the thickness of the wire being a certain 'gauge', for example, 11 or 12 gauge. Oddly, the higher the number of the

gauge, the thinner the wire. Thus, 11 gauge corresponds to a thickness of 0.120 inches, and a 12 gauge corresponds to a thickness of only 0.105 inches. Although gauges can vary between 6 and 14, the most common gauges for chain link fencing are 11, 11.5 and 12 gauge.

Finishes

Chain link fence is normally made from zinc galvanized steel wire, with the galvanizing being applied either before or after the weaving of the wire. It is preferable for the galvanizing to the applied before weaving, to ensure that all surfaces are fully galvanized. Of course, you can also select the PVC/PE coated chain link fence.

Edge type: Closed edge and twisted barbed edge

5.chain link fence fittings (terminal post, end post, corner post, gate post, line pot installing) :

Tenis Play Ground Chain Wire Fence 50mm x 50mm ,chain wire park chain wire fencing for sale

chain link fence fittings installation live-action :

Tenis Play Ground Chain Wire Fence 50mm x 50mm ,chain wire park chain wire fencing for sale

Packaging & Shipping

Packaging: Both ends are wrapped with plastic cloth and mesh bag, and then into the container. Special packaging requests are also accommodated.

Shipping: 15-20 days after we receive your payments

Tenis Play Ground Chain Wire Fence 50mm x 50mm ,chain wire park chain wire fencing for sale
