Heavy duty galvanized livestock cattle panel used corral panels

Name: Heavy duty galvanized livestock cattle panel used corral panels
Brand: wiremeshfence.com/buy-farm_fence.html
Price: 8.88 USD

China Heavy duty galvanized livestock cattle panel used corral panels factory

Brand Name : wiremeshfence.com/buy-farm_fence.html

Model Number : 1.6m 1.8m height 5 bar 6 bars

Certification : ISO

Place of Origin : American Design China Made

MOQ : 500 liner meter

Price : 8.88$ per liner meter

Payment Terms : TT30% deposit balance 70% at sight of finished products

Supply Ability : 10000 liner meters

Delivery Time : 7 work days

Packaging Details : All metal Pallets

Materials : Q235 steel pre hot dipped galvanized steel pipe

Color : Any Ral Color

Treatment : Hot Dipped Glavanized,Powder Coated

Thickness : 1.2-2.5mm

Type : Weld panels

Warranty : 5 -25 years depand on the treatment

Main Market : Oceania Europea ,Middle East ,USA ,AU etc

Accessoires : 2 rain caps + 2 "U" lugs + 2 "L" lugs + 2 pins + 2 footplates

Customized : Available

Sample : Free but pay freight cost

Square pipes : 40*40mm*1.6mm,50*50*1.6m

Round Pipes : 32mm,42mmO.D,1.6mm thick

Oval Pipes : 30*60*1.6mm,40*80*1.6mm

Height : 1.6m high with 5 bars,1.8m

Name : Heavy duty galvanized livestock panel ,cattle panel ,horse pane, ,sheep panels

Stanard Size : 1800x2100,1600mm x 2100mm

Contact Now

US standard Heavy duty galvanized livestock cattle panel used corral panels

Heavy duty horse fence panel is made of welded hot dip galvanized pipes and wire for the use of fencing livestocks ,such as cattle,cow,bull,calves,dairy sheep,goat,hog.

Square Tubes Style:

Height x Length	1800mm x 2100mm ( 6 rails ); 1600mm x 2100mm ( 5 rails ) Different specifications are available according to customers’special inquiry or detailed drawings.
Vertical Pipe	40 x 40 x 1.6mm/2.0mm; 50 x 50 x 1.6mm/2.0mm
Horizontal Pipe	40 x 40 x 1.6mm/2.0mm; 50 x 50 x 1.6mm/2.0mm

Round Tubes Style:

Height x Length	1800mm x 2100mm ( 6 rails );1600mm x 2100mm ( 5 rails ) Different specifications are available according to customers’special inquiry or detailed drawings.
Vertical Pipe	32mm OD x 1.6mm/2.0mm; 42mm OD x 1.6mm/2.0mm
Horizontal Pipe	32mm OD x 1.6mm/2.0mm; 42mm OD x 1.6mm/2.0mm

Packaging Details:	bull panel fence: 1. fence panel: plastic flim+wood/metal pallet 2. fence post: every post pack with a plastic bag(the cap is covered well on the post)+metal pallet 3. accessory: small plastic bag+carton box 4. we can also do like your details
Delivery Detail:	15 working days after receiving your deposit

Specifications

bull panel fence
1.square/round/oval pipes
2.material: HDG pipes
3.ISO9001; CE
4.direct sale

sheep/cattle/buffalo/bull/bovine/cow /corral panel/ paddock fence/farm gates

1. Material:

First-grade pre-hot dipped galvanised tubes --- 60 / 100 / 200 g/m2 Zinc coating on both inside and outside of the material

Square Tubes / Square Hollow Sections	40 x 40 x 1.6mm/2.0mm; 50 x 50 x 1.6mm/2.0mm
Oval Tubes / Oval Rails	30 x 60 x 1.6mm/2.0mm; 40 x 80 x 1.6mm/2.0mm
Round Tubes / Round Rails	32mm OD x 1.6mm/2.0mm; 42mm OD x 1.6mm/2.0mm

2. Specifications:

a. Square Tubes Style:

Material	Pre-hot dipped galvanized steel pipe
Zinc Coating	More than 15 microns
Height x Length	1800mm x 2100mm ( 6 rails ); 1600mm x 2100mm ( 5 rails )
Vertical Pipe	40 x 40 x 1.6mm/2.0mm; 50 x 50 x 1.6mm/2.0mm
Horizontal Pipe	40 x 40 x 1.6mm/2.0mm; 50 x 50 x 1.6mm/2.0mm
Welding	Fully welded
Finishing / Surface Treatment	1). Wipe antirust paint on welding seams 2). Wipe antirust paint on welding seams + silver spray painted on the welding seams 3). Silver spray painted on the whole panel
Accessories	1 set = 2 rain caps + 2 "U" lugs + 2 "L" lugs + 2 pins + 2 footplates

b. Oval Tubes Style:

Material	Pre-hot dipped galvanized steel pipe
Zinc Coating	More than 15 microns
Height x Length	1800mm x 2100mm ( 6 rails ); 1600mm x 2100mm ( 5 rails )
Vertical Pipe	40 x 40 x 1.6mm/2.0mm; 50 x 50 x 1.6mm/2.0mm square pipes
Horizontal Pipe	30 x 60 x 1.6mm/2.0mm; 40 x 80 x 1.6mm/2.0mm oval rails
Welding	Fully welded
Finishing / Surface Treatment	1). Wipe antirust paint on welding seams 2). Wipe antirust paint on welding seams +silver spray painted on the welding seams 3). Silver spray painted on the whole panel
Accessories	1 set = 2 rain caps + 2 "U" lugs + 2 "L" lugs + 2 pins + 2 footplates

c. Round Tubes Style:

Material	Pre-hot dipped galvanized steel pipe
Zinc Coating	More than 15 microns
Height x Length	1800mm x 2100mm ( 6 rails ); 1600mm x 2100mm ( 5 rails )
Vertical Pipe	32mm OD x 1.6mm/2.0mm; 42mm OD x 1.6mm/2.0mm
Horizontal Pipe	32mm OD x 1.6mm/2.0mm; 42mm OD x 1.6mm/2.0mm
Welding	Fully welded
Finishing / Surface Treatment	1). Wipe antirust paint on welding seams 2). Wipe antirust paint on welding seams + silver spray painted on the welding seams 3). Silver spray painted on the whole panel
Accessories	1 set = 2 rain caps + 2 "U" lugs + 2 "L" lugs + 2 pins + 2 footplates

3. Producing Process:

1). Pre-hot dipped galvanized steel pipe -- welding -- polishing -- wipe antirust paint on welding seams

2). Pre-hot dipped galvanised steel pipe -- welding -- polishing -- wipe antirust paint on welding seams -- silver spray painted on the welding seams

3). Pre-hot dipped galvanised steel pipe -- welding -- polishing -- silver spray painted on the whole panel

4. Welding Characters:

-- 360 degrees firmly welded
-- Welding spots neat and smooth, prevent sheep and goat get hurt, very safe
-- Welding spots anti-rust finish, very durable

5. Unique Design:

-- Square vertical pipe/post, welding easy and firm, much durable, and it's more beautiful
-- Oval horizontal rails, no sharp edge, can protect sheep and goat from getting hurt, high safety
-- Lamb-proof rail spacing
-- Middle braces for high strength and heavy duty
-- With welded top caps and foot plates, water and dustproof
-- Welded "U" and "L" lugs for easy connection. The lugs are welded to bracket all four sides, very durable.
-- 2xjoining pins are supplied for each panel

-- Footplate on the panel, can cement the panels on the ground by nails.

-- Easily assembled & disassembled

Only welding panels, no polish, no surface treatment:

6. Cattle Panel Gates -- Heavy Duty Swing Gates:

Height x Length	2200mm x 2000mm
Frame	Horizontal & Vertical pipe: 50 mm x 50 mm RHS x 1.6 mm with fully welded caps
Cattle Gate Horizontal Rail	40 mm x 80 mm x 1.6mm thick x 6 oval anti-bruise rails "Bull bars" rails
Zinc Coating	HDG - 15 microns
Finishing / Surface Treatment	1). Wipe antirust paint on welding seams 2). Wipe antirust paint on welding seams + silver spray painted on the welding seams 3). Silver spray painted on the whole panel
Welding	Fully welded oval pipes, post & brackets, heavy-duty hinges
Accessories	Supplied with two HDG Bolt Pins with Nuts

7. Other Specifications:

a. Heavy duty cattle panels:

Height x Length	1800mm x 2100mm
Vertical Pipe	50mm x 50mm RHS fully welded caps
Horizontal Rail	40mmx 80mm x 6 oval anti-bruise rails" Bull bars"
Finish	HDG 15-microns
Welding	Fully welded oval pipes, post &brackets
Accessories	Supplied with two HDG bolt pins with nuts

b. Heavy duty Man-way Swing Gates :

Height x Inner Width	2200mm x 750mm / 800mm
Frame	Horizontal & Vertical pipe: 50mm x 50mm RHS with fully welded caps
Cattle Gate Horizontal Rail	40mmx 80mm x 6 oval anti-bruise rails "Bull bars"
Finish	HDG 15-microns
Welding	Fully welded oval pipes, post &brackets, heavy duty hinges
Accessories	Supplied with two HDG bolt pins with nuts

c. Heavy duty Sliding Gates:

Height x Inner Width	2200mm x 750mm / 800mm
Frame	Horizontal & Vertical pipe: 50mm x 50mm RHS with fully welded caps
Horizontal Rail	40mmx 80mm x 6 oval anti-bruise rails "Bull bars"
Finish	HDG 15-microns
Welding	Fully welded oval pipes, post &brackets, heavy duty hinges
Accessories	Supplied with two HDG bolt pins with nuts

d. Heavy duty race bow:

Height x Width	1800mm x 750mm / 800mm
Frame	40 x 40 x 1.6mm/2.0mm; 50 x 50 x 1.6mm/2.0mm
Finish	HDG 15 - microns
Welding	Fully welded brackets
Accessories	Supplied with two HDG bolt pins with nuts

8. Trade Terms:

Trade Terms: FOB, CFR, CIF,
Payment terms: T/T, L/C, Western Union, Escrow, etc
MOQ: 100sets
Port: TIANJIN
Sample time: 5-7days
Lead time: 15-25days depend on the final order quantity
Shipment: By sea
Supply capability:9000sets/month
Sample Availability: Yes
Packing: plastic film and pallet

9. Our Service:

1.15 days after receiving the deposit shipment
2. We will choose a high-quality low price of the shipping company
3. Loading the goods, we will track all the way, to ensure product safety, quick to arrive at the designation ports
4. The arrival of the goods, we will provide installation instructions and subsequent technical guidance

Heavy duty galvanized livestock cattle panel used corral panels

10. Company Information:

Company’s name: TOP FENCE CO.LTD
Areas: 19980m2
No. of Employees: 120
Cartographers: 5, we can design drawings as clients’ requirements
Personnel for preparing samples: 5
No. of QA/QC Inspector(s): 5
Overseas Markets: Europe, South America, Australia, North America, Asia etc.
Annual Revenue: USD14,724,000
Certificates: BV report, CE certificate, ISO9001 certificate, SGS certificate, IFA certification, etc
